• BF-111G

BF-111G

RESILIENT SEATED BUTTERFLY VALVE-CONCENTRIC TYPE
GROOVED TYPE.

BODY: DUCTILE IRON A536
DISC: DUCTILE IRON A536 WITH EPDM
SHAFT: AISI 420/431/304/316 (stem)
BUSHING: PTFE
O-RING: BUNAN OR EPDM
CONN: GROOVED TYPE
INSPECTION & TESTING: API 598
MOUNTING FLANGE: ISO 5211
SIZE: DN50-DN300 (2”~12”)
OPERATOR: LEVER, GEAR OPERATOR WITH INDICATOR FLAG.
(BF-111G) BUTTERFLY VALVE GROOVED TYPE


(BF-11G) RESILIENT SEATED BUTTERFLY VALVE
CONCENTRIC - GROOVED TYPE

MODEL:
BF-111G    GROOVED type

* Please specify the required Model No. when ordering
* Optional: Lever Handle, Gear Operator
* Valve Designed to MSS SP-67
* Ends: AWWA C606
* Inspection & Testing: API 598
* Mounting Flange: ISO 5211
* Material: DUCTILE IRON A536
* Body Configuration: Grooved type
* Disc/Stem Connection: Two piece shafts
* Range: DN50-DN300 (2”~12”)
* Rating: 300 PSI

Applicable:
_Portable water
_Water & Wastewater treatment
_Irrigation
_Food & Beverage
_Textile line
_Vacuum System
_Chemical Processing
_Transportation
_Pulp & Paper
_Automation




(BF-11G) RESILIENT SEATED BUTTERFLY VALVE
CONCENTRIC - GROOVED TYPE.

MODEL:
BF-111G    GROOVED type

INSPECTION & TESTING: API 598
MOUNTING FLANGE: ISO 5211
OPERATED: LEVER HANDLE, GEAR OPERATOR
SIZE: DN50-DN300 (2”~12”)

DISC/STEM Connection:
T type: Two pieces shafts (stem)

Material Specification:
1. BODY: DUCTILE IRON A536
2. DISC: DUCTILE IRON A536 WITH EPDM
3. STEM: AISI 420/431/304/316 (shaft)
5. BUSHING: PTFE
6. O-RING: BUNAN OR EPDM
