UAW

CAST BRONZE SOLENOID VALVE
NORMALLY CLOSED. SCREWED END
BSPT, NPT, BSP. AC110/220V, DC24V.
FOR WATER, AIR USE. SIZE: 1/2”~2”
PRESS: 0.5-10 KGF/CM2 TEMP: -5~80℃.
(UAW Series) MULTIPLEX, PILOT OPERATED PISTON, CONDUCTIVE AND NORMALLY CLOSED SOLENOID VALVE

  1. UAW SERIES IS MULTIPLEX-DRIVE, PISTON GUIDE, AND CONDUCTIVE NORMAL CLOSE.
  2. VALVE BODY MADE OF CAST BRONZE.
  3. STANDARD VOLTAGE: 110VAC / 220VAC / 24VDC. (50/60HZ)
  4. SPECIAL VOLTAGE AC/DC FOR CUSTOMER MADE.
  5. SCREWED END: BSPT, NPT, BSP.
  6. IN CASE THE PRESSURE RANGE IS MORE THAN 15KGF/CM2 (WITH IN 20 KGF/CM2) PLEASE STATE THE TYPE OF FLUID WHEN ORDER.
  7. NORMAL WORKING TEMPERATURE: 80℃ (NBR).
  8. AC VOLTAGE TOLERANCE: +/- 10%
    DC VOLTAGE TOLERANCE: +/- 1%
  9. NOT APPLY FOR FLUID OF
    LIQUID STATUS WHEN HEAT, SOLID STATUS WHEN COOL.
    VISCOSITY OVER 20 CST.
    CORROSIVE FLUID.
(UAW Series) SOLENOID VALVE
MODEL: UAW Series (WATER)
