SKW of Explosion Proof Series Solenoid Valve

CF8 2-WAY SOLENOID VAVLE
EXPLOSION PROOF PROTECTION: EX II2 G EX E MB IIC T4 GB
WATER PROOF PROTECTION: IP67
NORMALLY CLOSED. SCREWED END
BSPT, NPT, BSP. AC110V/220V, DC24V.
FOR WATER, AIR, GAS, VACUUM.
1/2”~1” P: 0-7K (AIR) 0-5K (WATER)
TEMP: -5~70℃.
(SKW OF EXPLOSION PROOF EX II2 G EX E MB IIC T4 GB Series) DIRECT, MULTIPLEX, CONNECTED DIAPHRAGM CONDUCTIVE AND NORMLLLY CLOSED SS316 SOLENOID VALVE 3/8

  1. SKW SERIES IS DIRECT MULTIPLEX-DRIVE, CONDUCTIVE TO DIAPHRAGM, NORMAL CLOSE.
  2. VALVE BODY MADE OF INVESTMENT CASTING S/S 304.
  3. SKW CAN BE OPERATED DIRECTLY UNDER LOW PRESSURE.
  4. STANDARD VOLTAGE: 110VAC / 220VAC / 24VDC. (50/60HZ)
  5. SCREWED END: BSPT, NPT, BSP.
  6. AMBIENT TEMPERATURE  NOT EXCEED: 70℃
    OPERATING TEMPERATURE  NOT EXCEED: 60℃

    OTHERS: VITON (130℃), SILICON (130℃) WHEN REQUESTED.
  7. AC VOLTAGE TOLERANCE: +/- 10%
    DC VOLTAGE TOLERANCE: +/- 1%
  8. NOT APPLY FOR FLUID OF
    LIQUID STATUS WHEN HEAT, SOLID STATUS WHEN COOL.
    VISCOSITY OVER 20 CST.
    CORROSIVE FLUID.

(SKW Series) SOLENOID VALVE
MODEL: SKW Series (EXPLOSION PROOF Series)
