SUW-80F
CF8M 2-WAY SOLENOID VALVE
NORMALLY CLOSED. FLANGED JIS10K DRILLED.
AC110V/220V, DC24V. FOR WATER, AIR, LIGHT OIL USE.
SIZE: 3” PRESS: 0.5-8K (WATER, AIR) 0.5-5K (LIGHT OIL)
TEMP: -5~80℃.
NORMALLY CLOSED. FLANGED JIS10K DRILLED.
AC110V/220V, DC24V. FOR WATER, AIR, LIGHT OIL USE.
SIZE: 3” PRESS: 0.5-8K (WATER, AIR) 0.5-5K (LIGHT OIL)
TEMP: -5~80℃.
(SUW-80F Series) SOLENOID VALVE
- SUW-80F SERIES IS MULTIPLEX, PILOT OPERATED DIAPHRAGM, CONDUCTIVE AND NORMALLY CLOSED.
- VALVE BODY MADE OF INVESTMENT CASTING S/S 316.
- SUW-80F SHOULD START PRESSURE AT 0.5 KGF/CM2.
- STANDARD VOLTAGE: 110VAC / 220VAC / 24VDC. (50/60HZ)
- SPECIAL VOLTAGE AC/DC FOR CUSTOMER MADE.
- FLANGED END TO: JIS 10K DRILLED.
-
NORMAL WORKING TEMPERATURE: NBR (80℃).
-
AC VOLTAGE TOLERANCE: +/- 10%
DC VOLTAGE TOLERANCE: +/- 1% -
NOT APPLY FOR FLUID OF
●LIQUID STATUS WHEN HEAT, SOLID STATUS WHEN COOL.
●VISCOSITY OVER 20 CST.
●CORROSIVE FLUID.
(SUW-80F Series) SOLENOID VALVE
MODEL: SUW-80F Series
MODEL: SUW-80F Series
