US mini
FORGE BRASS SOLENOID VALVE
NORMALLY CLOSED. SCREWED END
BSPT, NPT, BSP. AC110V/220V. DC24V
FOR STEAM USE.
SIZE: 1/8”~1/4” (0-7K AIR)
3/8” (0-10K STEAM)
TEMP: -5~185℃.
NORMALLY CLOSED. SCREWED END
BSPT, NPT, BSP. AC110V/220V. DC24V
FOR STEAM USE.
SIZE: 1/8”~1/4” (0-7K AIR)
3/8” (0-10K STEAM)
TEMP: -5~185℃.
(US Mini-Series) SOLENOID VALVE
- US MINI-SERIES IS DIRECT-ACTING, CONDUCTIVE, NORMAL CLOSE.
- VALVE BODY MADE OF FORGED BRASS.
- US CAN BE OPERATED DIRECTLY WITHOUT PRESSURE.
- SMALL SIZE AND EASY ASSEMBLY.
- STANDARD VOLTAGE: 110VAC / 220VAC / 24VDC. (50/60HZ)
- SPECIAL VOLTAGE AC/DC FOR CUSTOMER MADE.
- SCREWED END: BSPT, NPT, BSP.
-
NORMAL WORKING TEMPERATURE: 185℃ (PTFE).
-
AC VOLTAGE TOLERANCE: +/- 10%
DC VOLTAGE TOLERANCE: +/- 1% - US-6~US-10 PROVIDE STEAM SPECIFICATION.
-
NOT APPLY FOR FLUID OF
●LIQUID STATUS WHEN HEAT, SOLID STATUS WHEN COOL.
●VISCOSITY OVER 20 CST.
●CORROSIVE FLUID.
(US Mini-Series) SOLENOID VALVE
MODEL: US Mini-Series
