(AMS. AMS-H SERIES)
RUBBER EXPANSION JOINT
SINGLE SPHERE. NEO. WITH FLOATING
FLANGE SS41 TO JIS 10K, ASA 150LBS. DRILLED.
ELASTOMER: SYNTHETIC RUBBER
SIZE: 1”~28”
SINGLE SPHERE. NEO. WITH FLOATING
FLANGE SS41 TO JIS 10K, ASA 150LBS. DRILLED.
ELASTOMER: SYNTHETIC RUBBER
SIZE: 1”~28”
(AMS. AMS-H SERIES) SINGLE SPHERE RUBBER EXPANSION JOINT
(AMS.
AMS-H) SINGLE SPHERE RUBBER EXPANSION JOINT (FLOATING FLANGE)
* Please specify the required Model No. when ordering.
* The available Flange: JIS 10K, ANSI 150LBS
Fluid:
Water, Warm water, Seawater, Weak acid, Weak alkali, Compressed Air, etc.
Applicable:
_Air Conditioning system
1”~12”: 16 kg/cm2
14”~28”: 8 kg/cm2
* Please specify the required Model No. when ordering.
* The available Flange: JIS 10K, ANSI 150LBS
Fluid:
Water, Warm water, Seawater, Weak acid, Weak alkali, Compressed Air, etc.
Applicable:
_Air Conditioning system
_Air ducts,
Chemical lines
_Circulating water lines
_Compressor lines, paper stock lines
_Pump-suction and discharge
_Refrigeration lines
_Turbine to condenser
Working Pressure: _Circulating water lines
_Compressor lines, paper stock lines
_Pump-suction and discharge
_Refrigeration lines
_Turbine to condenser
1”~12”: 16 kg/cm2
14”~28”: 8 kg/cm2
