AMSU
RUBBER EXPANSION JOINT
SINGLE SPHERE. FCD TRIANGLE FLANGE.
WITH FCD THREADED UNION.
VACUUM 26” HG.
BODY: 1/2”~2”
SINGLE SPHERE. FCD TRIANGLE FLANGE.
WITH FCD THREADED UNION.
VACUUM 26” HG.
BODY: 1/2”~2”
(AMSU SERIES) SINGLE SPHERE RUBBER EXPANSION JOINT (UNION TYPE)
(AMSU) SINGLE
SPHERE RUBBER EXPANSION JOINT (UNION TYPE)
* Please specify the required Model
No. when ordering.
* The available Thread: BS21 or ANSI B2.1
* Efficient noise and vibration isolation
*
Ability to absorb large displacement due to eccentric, axial, and angular
movement
* Applicable for both suction and discharge
* Working pressure: 10 kg
* Normal Operation Temp: -10℃ ~ 70℃
Applicable:
_Air Conditioning system and Air ducts
_Circulating
water lines
_Pump-suction
and discharge
_Sewage disposal purifier line
_Small
pump, circular pumps
