SV-BS9DA/SVP-BS9DA
BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-BS9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-BS9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)
(SV-BS9DA/SVP-BS9DA) BRONZE SAFETY RELIEF VALVE (1x2)
" 317 " BRAND BRONZE SAFETY RELIEF VALVE SEAT/DISC: CF8.
SCREWED END TO BSPT, NPT. WITHOUT LEVER. SET: 0.3-10 KGS. 317 SEAL OF SAFETY
RELIEF VALVE (LOW LIFT & FULL BORE) OF T-ONE-S TRADING INC. TAIWAN
MANUFACTURER
(SV-BS9DA) BRONZE SAFETY RELIEF VALVE (1x2)
MODEL:
SV-BS9DA / SVP-BS9DA (NO LEVER)
SV-BS9DL / SVP-BS9DL (WITH LEVER)
When placing order, please indicate Working Pressure
(Spring adjusting range: ± 1 kg/cm2)
The features of low lift bronze safety valves for which the valve seat & disc are processed by lapping.
The Disc can be replaced with PTFE for good effect of anti-leakage. (Model: SVP-BS9DA, SVP-BS9DL)
(SV-BS9DA) BRONZE SAFETY RELIEF VALVE (1x2)
MODEL:
SV-BS9DA / SVP-BS9DA (NO LEVER)
SV-BS9DL / SVP-BS9DL (WITH LEVER)
When placing order, please indicate Working Pressure
(Spring adjusting range: ± 1 kg/cm2)
The features of low lift bronze safety valves for which the valve seat & disc are processed by lapping.
The Disc can be replaced with PTFE for good effect of anti-leakage. (Model: SVP-BS9DA, SVP-BS9DL)
