V-1FWH.V-1FWH-04.V-1FWH-C
1-PC WAFER TYPE BALL VALVE
FLANGE DIRECT MOUNTING PAD
BODY: CF8M / CF8 / WCB
DIN 1.4408 / 1.4308 / 1.0619
FLANGED END TO PN16.
SIZE: 1/2”~4”
FLANGE DIRECT MOUNTING PAD
BODY: CF8M / CF8 / WCB
DIN 1.4408 / 1.4308 / 1.0619
FLANGED END TO PN16.
SIZE: 1/2”~4”
(V-1FWH/V-1FWH-04.V-1FWH-C) 1-PC WAFER TYPE BALL VALVE FLANGE DIRECT MOUNTING PAD
(V-1FWH. V-1FWH-04. V-1FWH-C) 1-PC WAFER TYPE BALL VALVE
MODEL:
V-1FWH (CF8M / 1.4408)
V-1FWH-04 (CF8 / 1.4308)
V-1FWH-C (WCB / 1.0619)
* Please specify the required Model No. when ordering.
* Flanged end : PN16
* Blow-out proof stem / Full Bore / Solid Ball
* Investment casting body and cap
* Body: 1.4408 / 1.4308 / 1.0619
* With ISO 5211 Direct Mounting Pad
* Anti-static device, fire safe design
* Option: Locking Device
MODEL:
V-1FWH (CF8M / 1.4408)
V-1FWH-04 (CF8 / 1.4308)
V-1FWH-C (WCB / 1.0619)
* Please specify the required Model No. when ordering.
* Flanged end : PN16
* Blow-out proof stem / Full Bore / Solid Ball
* Investment casting body and cap
* Body: 1.4408 / 1.4308 / 1.0619
* With ISO 5211 Direct Mounting Pad
* Anti-static device, fire safe design
* Option: Locking Device
