YG-316
ST.ST.316 Y-GLOBE VALVE
CLASS 600. SCREWED END TO
BS21, ANSI B2.1, DIN-259.
BODY: CF8M
SIZE: 1/4”~2”
CLASS 600. SCREWED END TO
BS21, ANSI B2.1, DIN-259.
BODY: CF8M
SIZE: 1/4”~2”
(YG-316) STAINLESS STEEL Y-GLOBE VALVE CLASS 600
(YG-316) STAINLESS STEEL Y-GLOBE VALVE
CLASS 600
* Please
specify the required Model No. when ordering
*
Investment casting body & cap
* The available THREAD: ANSI B2.1, BS21 or DIN-259.
*
Pressure rations 600 PSI
* Temperature rations WSP/350℉
* ASTM-A351,
CF8M, Class 600, Inside screw and Screwed bonnet
* Wedge disc, Integral seat, Non-rising stem, and Handwheel
Applicable:
_Petrochemical industry lines
_Chemical lines
_Circulating
water lines
_Air
Conditioning, Fire, and Steam system
_Factory lines
